Type of measurement | Current |
Voltage |
Frequency |
Power factor |
Energy |
Active and reactive power |
supply voltage | 90...450 V AC 45...65 Hz |
100...300 V DC |
Network Frequency | 50 Hz |
60 Hz |
Line Rated Current | 1:00 AM |
5:00 AM |
type of network | 1P + N |
3P + N |
3P |
Maximum power consumption in VA | 11 VA 415 V |
Ride-through time | 80 ms 120 V AC typical |
100 ms 230 V AC typical |
100 ms 415 V AC typical |
50 ms 125 V DC typical |
display type | Monochrome graphic LCD |
Display Resolution | 128 x 128 pixels |
Sampling rate | 64 samples/cycle |
Measurement current | 50…8500 mA |
Analogue input type | Voltage (impedance 5 MOhm) |
Current (impedance <= 0.3 mOhm) |
Measurement voltage | 35…760 V AC 45...65 Hz between phases |
20…440 V AC 45...65 Hz between phase and neutral |
Frequency measurement range | 45…65 Hz |
Number of inputs | 0 |
Measurement accuracy | Active energy +/- 0.5 % |
Reactive energy +/- 2 % |
Active power +/- 0.5 % |
Apparent power +/- 0.5 % |
Frequency +/- 0.05 % |
Power factor +/- 0.5 |
Current +/- 0.5 % |
Voltage +/- 0.5 % |
Apparent energy +/- 0.5 % |
Reactive power +/- 2 % |
Accuracy class | Class 0.5S active energy IEC 62053-22 |
Number of Outputs | 1 digital |
Communication port support | RS485 |
data recording | Time stamping |
Min/max of instantaneous values |
Connections - terminals | Voltage circuit screw terminal block4 |
Control circuit screw terminal block2 |
Current transformer screw terminal block6 |
Input/output circuit screw terminal block6 |
RS485 link screw terminal block4 |
Mounting Mode | Flush-mounted |
Mounting support | Framework |
Standards | UL 61010-1 |
EN 50470-3 |
EN 50470-1 |
IEC 62053-22:2020 |
IEC 60529 |
IEC 62053-24 |
IEC 61557-12:2015 |
IEC 62053-23:2020 |
IEC 62052-11:2020 |
IEC 62052-31:2015 |
